Ultrasonic Heat Meter

Our ultrasonic heat meters are specially designed for HVAC household heating metering and billing, as well as heat distribution in public or centralized community heating systems. Compared with traditional mechanical heat meters, ultrasonic heat meters feature no moving components, thus being wear-free and stable for a long period of time.

This series of ultrasonic meters combines the ultrasonic flow meter and resistance temperature sensor. Once the water flows past the ultrasonic heat meter, the inside flow sensor computes the flow rate. The temperature sensors are installed on the water supply pipe and exhaust water pipe to indicate the temperature difference and feed back to the heat meter. Then the heat meter will compute automatically and display the heat amount released or absorbed by the system.

• Users can set the time on their own for time-based metering in different periods.
• Ultrasonic heat meter features no dead angle foe deposit and it is not affected by the impurities, chemical substances and magnetic materials in the flow media.
• PN25 pressure grade: the technical specification is in accordance with the residential standard for meters.
• Ultrasonic heat meter comes in different output interfaces like M-Bus, RS485 / MODBUS, BACnet / MSTP and wireless to adapt to different applications.

If the M-Bus module is applied, this heat meter can be connected with central network through bi-wire bus for integrated energy management.
